ASTM B168 Inconel 600 Plate
Nickel Alloy 600 Sheet supplier in India
Inconel 600 Plate
Inconel 600 Sheet
Inconel 600 Coil
UNS N06600 / 2.4816 Alloy 600 Strips, Coil and Foil stockist in Mumbai
Inconel 600 Plate is typically used in high temperature applications. Compared to most stainless steel alloys, a Inconel 600 Clad Plate made from Alloy 600 material won’t lose shape as easily when holding parts through a rigorous heat treat application. Cutting of UNS N06600 Plate is often done with a waterjet cutter. Internal threads can also be cut by single point method on lathe, or by threadmilling on a machining center. Welding Inconel Alloy 600 Plate is difficult due to cracking and microstructural segregation of alloying elements in the heat affected zone. But Inconel 600 Plate retains strength over a wide temperature range, attractive for high temperature applications. Alloy 600 Plate is oxidation and corrosion resistant materials well suited for service in extreme environments subjected to pressure and heat. Inconel Alloy 600 Foils also called with specification like NA14 Plate, N06600 Plate, BS3076 Plate, ASTM B166 Plate, 2.4816 Plate, NCr15Fe (FR) Plate, NiCr15Fe (EU) Plate and NiCr15Fe8 (DE) Plate. Inconel 600 Flat Shim, Inconel 600 Perforated Plate & Inconel 600 Rolling Sheets can be cold formed by standards methods.
Looking for best price of ASTM B168 UNS N06600 in India? We have no minimum footage requirements. We will supply the exact amount of Inconel 600 Strip you require even if it’s small quantity of Inconel 600 Sheet. Contact Nirmaan Steel- the right supplier of Alloy 600 Foil near you.
Nirmaan Steel offers one of the widest ranges of ASTM B 168 Inconel 600 Plate and AMS 5540 Sheet in various qualities, sizes and grades which are equivalent to Inconel 600 Sheet & Inconel 600 Plate (2mm to 12mm). Inconel 600 Sheet is available in thicknesses ranging from .016 to .156″. Large size Inconel 600 ASTM B168 Plate will also diminish the size of the undesirable heat-affected zone caused by welding. We also stock & supply extra large-size Inconel 600 Sheets, thin and ultra-thin gauge Inconel Alloy 600 strip and foil products, rolled down to 2 microns.
Superior technology as well as extensive quality control from steelmaking to finishing assure the stable production of 2.4816 Alloy 600 Plate in uniformly of excellent quality. We apply the process of surface finishing to our Inconel 600 Polished Plate by pickling or buff-polishing. Inconel 600 Strips levels of finishing & cut can be adjusted according to your requirements. Inconel 600 Plate is available in the form of Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate and Flat Shim. The Inconel 600 Plate Weight Calculator allows you to calculate an estimate of the weight of different sizes of Inconel 600 plates based on dimensions and shape. Inconel 600 Shim is sold in either 300mm or 600mm rolls and sheet form. The thin material can be used in power plants, nuclear plants or gas and oil refineries.
Our Dealers & Distributors in India arrange complete range of Inconel 600 plates in shortest time as well at best price, because we maintain Inconel 600 Sheet in stock for sale, so it saves time & cost to procure any size range in Bright annealed Inconel 600 sheet from any other vendor or Manufacturer of mirror finish Inconel 600 plate in India.
Table of contents
Looking to buy Inconel Plate andSheet? Inconel Plate and
Check price of Inconel Plate in India
Inconel 600 Plate Price
Inconel 600 Sheet Price in India
Price List for Inconel 600 Sheet Cut to Size. Please contact sales department for price of full size sheet or large quantity inquiry.
| Size | 0.018 | 0.020 | 0.025 | 0.032 | 0.043 | 0.050 | 0.062 | 0.078 | 0.093 | 0.125 |
|---|---|---|---|---|---|---|---|---|---|---|
| 12×12 | $299 | $303 | $314 | $326 | $337 | $351 | $373 | $424 | $455 | $580 |
| 12×24 | $338 | $347 | $368 | $392 | $414 | $443 | $487 | $637 | $699 | $851 |
| 12×36 | $371 | $383 | $413 | $447 | $478 | $570 | $632 | $774 | $963 | $1,177 |
| 12×48 | $407 | $424 | $465 | $560 | $601 | $656 | $739 | $1,029 | $1,147 | $1,583 |
| 24×24 | $407 | $424 | $465 | $560 | $601 | $656 | $739 | $1,029 | $1,147 | $1,583 |
Please note: Price is subject to change without any prior notice.
Inconel 600 Sheet Price Per Kg in India
Inconel 600 sheet price per kg in India is Rs. 2062. Which would mean that in the UK, the price per kg of Alloy 600 Coil would be 23.13 Pounds. It is very important to note that this price fluctuates from time to time. Also important to know is that for what price Alloy 600 Foil is available in India, it does not mean that it will be available for the very same price in USA, UK, Japan, Singapore, China, Europe, etc. For example, in India, the price of UNS N06600 Plate, could be 30% less than what it is available for in the United Kingdom.
Alloy 600 plate Specification
Inconel Alloy 600 AMS 5540, ASTM B168
Inconel 600 Sheet ASTM Specification | ASTM B168 UNS N06600, ASME SB168 AMS 5540 Sheet, Strip and Plate |
|---|---|
Alloy 600 Plate Specification | MSRR, AMS, BS, ASTM B168 / ASME SB168 |
Inconel 600 Plate Length & Sizes | 1000 mm x 2000 mm, 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2m, 2.44m, 3m, 36″ X 120″ or 48″ X 144″, Cut to size available |
0.1mm to 100 mm Thk | |
Inconel 600 Plate Width | 10-2500mm |
Inconel 600 Sheet AMS | AMS 5540 |
Inconel 600 Sheet Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
Temper | Annealed |
Condition | Polished on both sides |
Inconel 600 Plate Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Inconel 600 Plate Stock in form of | Alloy 600 Plate, Sheet, Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Clad Plate, Rolling Sheet, Flat Sheet, Rolling Plate, Flat Shim, Blank (Circle), hot rolled, cold rolled, annealed, soft annealed, descaled, sheared, tread plate, Checker Plate |
Inconel 600 Plate ASTM Standard | ASTM A162, GB/T2054, DIN177502002, ASTM B127, ASTM B435, ASTM B582, ASTM B575, ASTM B168, ASTM B443, ASTM B463, ASTM B626, ASTM B536, etc |
High Quality Inconel 600 Sheet |
|
Inconel 600 profiling | To provide a full profiling service we use numerous profiling methods including:
|
Specialized in |
|
Nirmaan Steel offer a comprehensive services designed to add value to your project: plasma cutting, waterjet cutting, laser cutting, bending and mechanical processing, edge preparation, welding, sawing and shearing. | |
Inconel 600 Plate Stock
Inconel 600 2B Sheet
Decorative 8K Mirror Inconel 600 Sheet
Hairline Inconel 600 Sheet
No.4 Inconel 600 Sheet
Inconel 600 Plate
Inconel 600 Sheet
Inconel 600 Coil
Inconel 600 Clad Plate
Inconel 600 Strips
Inconel 600 Shim Stock
Inconel 600 Rolling Sheets
Inconel 600 Flat Sheet
Inconel 600 Rolling Plate
Inconel 600 Flat Shim
Inconel 600 Perforated Plate
Inconel 600 Polished Plate
Inconel 600 cold rolled sheet
Inconel 600 hot rolled plate
Alloy 600 Plate
Alloy 600 Sheet
Inconel 600 Quarto Plate
Inconel 600 Precision Strip
Alloy 600 Cold Rolled Coil, Strip And Sheet
Alloy 600 Hot Rolled Coil, Strip And Plate
Inconel 600 Sheet, Plate Stock List
Alloy | Product form | Dimension |
|---|---|---|
INCONEL 600 (75 Ni/16 Cr) | Strip; cold rolled, annealed | 0.10×150 x coil, 0.12 kg/m |
ALLOY 600 (75 Ni/16 Cr) | Strip; cold rolled, annealed | 0.40×200 x coil, 0.7 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 0.4×914.4 x coil, 3.03 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 0.5×1000 x coil, 4.14 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 0.7x1000x2000, 13.25 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 0.8×1219 x coil, 8.1 kg/m |
ALLOY 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 1.0×1220 x coil, 10.10 kg/m |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 1.2x1200x3000, 37.8 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, pickled, annealed | 1.6x1220x3600, 59 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed | 2.0x1200x3000, 62 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, annealed, pickled | 2.5x1200x3000, 76 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Sheet, Plate; cold rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 3.0x1220x3000, 92 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 4.0x1200x3000, 122 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 5.0x2400x6000, 606 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 6.0x2440x6000, 746 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Plate; hot rolled, descaled, annealed | 8.0x2000x4000, 564 kg/pce |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 10.0x2000x4000, 726 kg/pc |
ALLOY 600 (75 Ni/16 Cr) | Plate; hot rolled, soft annealed, descaled, sheared, tread plate, Checker Plate | 12.0x2000x3000, 616 kg/pc |
INCONEL 600 (75 Ni/16 Cr) | Plate; hot rolled, annealed | 20.0x915x1235, 193 kg/pc |
Dimensions: widths 1000/1220/1500 mm, lengths 2000/2500/3000 mm.
Thickness: 0.5, 0.6, 0.8, 1.0, 1.2, 1.5, 1.6, 1.8, 2.0, 3.0, 4.0, 5.0, 6.0, 8.0, 10.0, 12.0, 15.0, 20.0, 25.4
Difference between Inconel 600 Sheet, Plate & Foil
Difference between Sheet, Plate & Foil
Here are few points to recognised sheet, plate or foil:
If thickness greater than 6.35 mm is called a Inconel 600 Plate.
If thickness greater than 0.15 mm and less than 6.35mm is called a Inconel 600 Sheet.
If thickness less than 0.15mm is then its a Inconel 600 Foil.
Inconel Alloy 600 Sheet Properties
Inconel 600 Plate mechanical properties
Inconel 600 Plate, Sheet & Coil Chemical Composition
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 Plate | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
Alloy 600 Sheets, Plate & Coils Mechanical Properties
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 Plate | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
Equivalent Grades for Inconel 600 Sheets & Plate
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 600 Plate | 2.4816 | N06600 | NCF 600 | NA 13 | МНЖМц 28-2,5-1,5 | NC15FE11M | NiCr15Fe |
Inconel 600 Plate Weight
Inconel 600 plate weight can be obtained by using a plate weight calculator, which can easily be obtained online for free. ASTM B168 Plate has a UNS number of N06600. The Density of Alloy 600 Foil is 8.42 g/cm3 (0.304 lbs/in3). The Thermal Conductivity of Inconel 600 Plate is 15.9 W/m-°K(109 BTU/hr/ft2/ft/°F). The Specific Heat of Inconel 600 Plate is 444 J/kg-°K (0-100 °C) [0.106 BTU/lb-°F (32-212°F)]. Inconel 600 Plate has a Melting Range of 1354 – 1413 °C (2470 – 2575 °F). Alloy 600 Plate is used in various industries like Petrochemical Processing, Chemical Processing, Thermal Processing, Aerospace, etc.
Inconel 600 UNS N06600 Plate Sizes
| Sizes in Inches | Sizes in mm |
|---|---|
| .125″ | 3.18 |
| .134″ | 3.40 |
| .156″ | 3.96 |
| .187″ | 4.75 |
| .250″ | 6.35 |
| .312″ | 7.92 |
| .375″ | 9.53 |
| .500″ | 12.7 |
| .625″ | 15.9 |
| .750″ | 19.1 |
| .875″ | 22.2 |
| 1″ | 25.4 |
| 1.125″ | 28.6 |
| 1.250″ | 31.8 |
| 1.500″ | 38.1 |
| 1.750″ | 44.5 |
| 2″ | 50.8 |
| 2.500″ | 63.5 |
| 3″ | 76.2 |
Metric Dimensions
| Surface finish | Thickness (mm) | Width (mm) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 0.25–8.0 | max. 2032 |
| 2D – Cold rolled, heat treated, pickled | 0.4–6.35 | max. 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled | 0.4–8.0 | max. 2032 |
| 2R – Cold rolled, bright annealed | 0.25–3.5 | max. 1524 |
| 2H – Work hardened | 0.4–6.35 | max. 1524 |
| Polished, brushed | 0.5–4.0 | max. 1524 |
Imperial Dimensions
| Surface finish | Gauge (in) | Width (in) |
|---|---|---|
| 2B – Cold rolled, heat treated, pickled, skin passed | 10–24 | max. 72* |
| 2D – Cold rolled, heat treated, pickled | 12–24 | max. 60 |
| BA Mexinox only | 18–28 | max. 48 |
| Polished (not brushed) | 11–24 | max. 60 |
| Temper rolled Mexinox only | 13–29 | max. 48 |
An estimated delivery time location wise for Inconel 600 Plate
| Country | Days | Country | Days |
|---|---|---|---|
| USA | 45 | Canada | 45 |
| Australia | 30 | UK | 35 |
| Malaysia | 15 | Poland | 15 |
| Iran | 7 | Singapore | 14 |
| Vietnam | 20 | Albania | 20 |
| UAE | 15 | Thailand | 20 |
| Nigeria | 40 | Ethiopia | 40 |
| Turkey | 30 | Tanzania | 30 |
| Bahrain | 15 | Kenya | 40 |
| Libya | 40 | Syria | 40 |
| Zambia | 40 | Egypt | 40 |
| Italy | 40 | India | 7 |
| Saudi Arabia | 15 | Qatar | 15 |
| Namibia | 40 | Indonesia | 20 |
| South Africa | 40 | Australia | 40 |
| Uganda | 40 | Angola | 40 |
| Kazakhstan | 20 | Algeria | 20 |
Inconel Alloy 600 Foils suppliers and UNS N06600 Plate for sale
